Superior material, excellent filtration, long service life
Effectively reduces 97.6% of chlorine, taste and odor.
Employs a high-quality coconut shell activated carbon with a filtration accuracy of 0.5 μm.
BPA-free and lead-free material ensures product safety.
Filtration capacity of 5,000 gallons and a fast water flow rate of 1.5 gpm.
AQUACREST Ultra High Capacity Under Sink Direct Connect Water Filtration System
This under sink water filtration system can be installed in your kitchen, bathroom, or office to meet your daily water needs. Ideal for drinking, cooking, washing, and pet feeding. With an additional adapter fitting, you can also connect the under sink water filter to your refrigerator. You will need to replace the inline water filter only once a year. Less expense, better filtration.
Efficient FiltrationThe under sink water filter effectively reduces 97.6% of chlorine, taste and odor.
Simple InstallationYou don’t need to drill any holes or cut any hoses. The under sink water filtration system comes with push-to-connect fittings, and you can finish the installation in 5 minutes.
All-inclusive AccessoriesThe under sink water filtration system comes equipped with a full set of accessories, which means you can easily finish the installation and enjoy filtered water for a long time.
Cooking
Washing
Feeding
Drinking
Step 1Turn off the cold water valve and turn on the faucet to ensure that there is no residual water.Reduce the cold water hose from the cold water valve.
Step 2Connect the 3/8” female compression end of the inlet hose to the cold water valve.Connect the other end of the inlet hose to the filter inlet.Connect the 3/8” male compression end of the outlet hose to the faucet hose. Connect the other end of the outlet hose to the filter outlet.
Step 3Select the proper fittings to fix the filter.Option 1-Bracket: Select the proper position on the cabinet wall. Install the bracket and then push the filter into the bracket.Option 2-Cable tie mounts: Take out 4 cable tie mounts and select the proper position for pasting them. Thread the cable ties into the cable tie mounts and fix the filter.
Step 4Turn on the cold water valve to flush the filter for 5 minutes. Check for any leakage.
To reduce the risk of property damage due to water leakage, this filter MUST be installed in accordance with the manufacturer's specifications and instructions.1. This filter unit must be replaced every 5,000 gallons or every 12 months.2. Do not use this product at temperatures under 32°F/0°C; otherwise, the product will freeze.3. Use municipal water as your source of water.
